60W 70W 80W LED Wall Pack Light
Our outdoor Commercial LED Wall Pack Lights are designed to replace 100W to 500W Metal Halide and HPS Commercial Wall Pack Lighting. LED outdoor wall packs are designed for commercial and industrial areas to light up building exteriors. Dusk to dawn LED wall packs with photocell and/or motion sensor are used for security lighting for office areas, businesses and warehouses to automatically light up when motion is detected, and turns on when the sun sets. We offer full flood and full cutoff wall pack options. We can even supply High Voltage solutions up to 480V. Our LED Wall Packs and Wall Pack lighting is easy to install providing bright and long lasting outdoor and security lighting business need.
Specification:
| Model | LL-XWPL60 | LL-XWPL70 | LL-XWPL80 |
| Wattage | 60W | 70W | 80W |
| Luminous Flux | 7800lm-10800lm | 9100lm-12600lm | 10400lm-14400lm |
| Lumens /Watt | 130 - 180 | ||
| Input Voltage | 100-277V / 277-480V / 100-347V,50 / 60 Hz | ||
| Color Temperature | 3000K / 4000K / 5000K / 5700K / 6500K | ||
| Operation Temperature | -40°C to + 50°C (-40°F to 122°F) | ||
| Beam Angle | 90º*65º | ||
| CRI | Ra70 (Ra80 or Ra90 optional) | ||
| PF | ≥0.95 | ||
| Net Weight | 2.0kg / 4.4lbs | 2.2kg / 4.9lbs | |
| QTY/CTN | 6 | ||
| GW/CTN | 14.8kg / 32.6lbs | 16.0kg / 35.3lbs | |
| Size of box(mm/in) | 330*260*150 / 13.0*10.3*5.9 | ||
| SIZE of CTN(mm/in) | 550*345*505 / 21.7*13.6*19.9 | ||
Size:
Unit: mm/in
Application:
The LED Wall Pack light is widely used on walls of Super Market, Hotel, Tavern, Night Club, Disco Hall, Karaoke Room, Coffee House, Bank, Meeting Room, Exhibition Hall, Exhibition Wardrobe, Show Window, Living House etc.
